Network Master Pro (以太網 / CPRI / FC / OTN / SDH / OTDR 測試儀)

MT1000A

MT1000A是一臺B5尺寸的便攜式測試儀，具有出色的可擴展性和可操作性。 測量可以通過單個測量模塊和10 G / 100 G以太網，OTN，OTDR，SONET / SDH，PTP，CPRI選項組合來執行。

一體化便攜式測試儀，具有出色的可擴展性和可操作性，適用于10 / 100G，OTDR和CPRI測試

一體化設計支持5G基站接口eCPRI / RoE吞吐量和延遲測量以及高精度時間同步測試。

• Various modules
  • OTDR Module (2波長,3波長,4波長)
  • Transport Module (10G)
  • Transport Module (100G)
• 通過一鍵式操作，輕松實現多項量測的自動化連接測試
• 適用于光纖檢查和數據通信測試的一體化便攜式測試儀
• 9 英寸彩色觸控屏，操作簡便
• Linux OS provides quick boot up and stable, virus free operation
• Easy and intuitive GUI
• Simple SETUP, TEST, RESULTS three window operation
• Modular design with field installable modules and options maximizes your investment
• WiFi/Bluetooth/LAN connectivity
• 通過 VNC 進行長期遠程連續測試
• Comprehensive, customizable report generation
• OTDR and 100G transport module can be simultaneously installed



Optical Fiber I&M

The compact, battery-powered and easy-to-use Anritsu MT1000A provides everything needed to install and maintain communication networks in a rugged, field portable package. This lightweight instrument simplifies the daunting task of collecting and interpreting data with an easy-to-use GUI and clear summaries allowing users of any skill level to operate the instrument to its full potential.

The MT1000A is multi-function tester that can be configured with an array of transport testing functions and OTDR modules to ensure you have the tools you need today plus the expandability for future technologies – all of which are field upgradeable.

• Verify proper fiber installation and fiber loss characteristics are within the specified budget
• Fiber Visualizer simplifies testing with an easy to read graphical summary of the results
• Ability to toggle between graphical summary and traditional OTDR trace
• Specialized testing modes simplify operation
• High resolution and dynamic range ensure quick and thorough fiber evaluation
• Intelligent analysis software identifies problem splices, connectors and even macrobends
• Test multiple wavelengths with a single unit
• One button PDF report generation
• Standard power meter and light source
• Visual fault locator option
• Verify fiber end face condition (dust, scratches) and cleanliness with optional connector inspection microscope

Transport Equipment Installation and Performance Tests

The MT1000A transport module provides robust Ethernet/IP client service verification using industry recognized benchmark test applications driven by IEEE, MEF & ITU-T standards bodies in an intuitive, easy to use graphic interface. It supports both electrical and optical Ethernet/IP industry standard interfaces from 10Mbps to 100Gbps in a scalable platform configured to your network requirements. The Network Master can generate, monitor, capture and report a variety of Ethernet/IP Client services including voice, data and video services. Also supported are Ethernet, IP, MPLS and PBB-TE packet transport as well as circuit based transport. The Network Master enables you to deliver confidence in your Ethernet/IP client service performance as your network grows and evolves with your business demands.

• All-in-one transport tester
  • Supports speeds from 1.5 Mbps to 100 Gbps
  • Support for current (Ethernet, eCPRI/IEEE1914.3/CPRI/OBSAI, OTN, Fibre Channel) and legacy (SONET/SDH/PDH/DSn) technologies Full suite of Ethernet benchmark tests RFC2544, Y.1564, RFC6349
• Simultaneous dual-port measurement at all rates
• WLAN*/Bluetooth*/LAN connections
• Test reports in PDF, CSV and XML formats



Mobile Base Station and Antenna Installation

• Two SFP ports for CPRI interface
• Analysis of RF IQ signal frequency characteristics for CPRI data
• Transmission of fixed IQ patterns

Features

• All-in-one field transport tester – supports testing from 1.5 Mbps to 100 Gbps
  • Metro and core networks OTN installation and maintenance
  • Carrier Class Ethernet installation and troubleshooting
  • Mobile backhaul installation and verification
  • Mobile fronthaul installation and verification
  • Powerful Storage Area Networking (SAN) testing
  • Quick and easy testing of SDH/SONET and PDH/DSn networks
• Testing of client signals mapped into OTN
• Easy and intuitive GUI
• Dual port at all rates
• WLAN^*/Bluetooth^*/LAN connectivity
• PDF, CSV and XML report generation for documentation of test results
• Remote operation (VNC), dedicated remote GUI software and remote control (scripting)
• Optical connector inspection



一體化現場傳輸測試儀

設計緊湊、電池供電的 MT1000A 簡單易用，內置 10G 多速率模塊 MU100010A 或 100G 多速率模塊 MU100011A，并在一款便攜式測試儀中集成了安裝和維護 1.5 Mbps 至 100 Gbps 通訊所需的功能。



• 城域網和核心網 OTN 安裝和維護
  • 高達 OTU4 的 OTN，包括以太網映射、CPRI、光纖通道、SDH/SONET 客戶端信號、多級映射和 FEC (前向糾錯)
  • OTN 新功能的測試和驗證：ODU0 和 ODUflex

• 電信級以太網安裝和故障排除
  • 高達 100 GigE 的以太網，包括 RFC 2544、RFC 6349 和 Y.1564 測試
  • 高達 100 GigE 的以太網 OAM
  • 高達 10 Gbps 的 MPLS-TP 和 PBB

• 移動回程安裝和驗證
  • 高達 25 GigE 的同步以太網 (ITU-T G.826x)  UPDATED
  • 時間/位相誤差測量 (ITU-T G.8265.1, ITU-T G.8275.1) (使用高性能 GPS 規律振蕩器MU100090A)

• 移動前傳安裝和驗證
  • 速率高達 100 Gbps 的eCPRI/ IEEE1914.3 測試
  • 速率高達 24.3302 Gbps 的 CPRI 測試  UPDATED
  • 速率高達 6 Gbps 的 OBSAI 測試

• 功能強大的存儲區域網絡 (SAN) 測試
  • 25G的以太網
  • 高達 16 Gbps 的光纖通道

• 快速輕松的 SDH/SONET 和 PDH/DSn 網絡測試
  • 高達 STM-64/OC-192 的 SDH/SONET
  • PDH/DSn (E1、E3、E4、DS1 和 DS3)

• Optical connector inspection and reporting to ensure network quality
  • IEC61300-3-35 based PASS/FAIL

客戶端信號的 OTN 測試

MT1000A 是一款功能強大的完整工具集，可用于測試 OTN 信號。它支持 OTN 級別上整體信號的完整誤碼率 (BER) 測試，以及至以太網、CPRI、光纖通道和映射到 OTN 信號的 SDH/SONET 客戶端信號的所有線路測試。

Automated Testing Reduces Onsite Work Load

The MT1000A has a built-in automatic test function, eliminating the need for an external controller, such as a PC. Testing is automated and test reports are created by loading pre-provided scenario files containing the test procedure and pass/fail evaluation conditions. Click here for details

簡單易用

MT1000A 小巧輕便，方便攜帶，使現場測試變得更為輕松。服務工程師可以直接在帶有簡單易懂標識和圖形符號的 9 英寸彩色顯示屏上解讀被測試的數據。此外，GUI 可輕松實現運行設備。

支持所有傳輸速度的雙端口



• 通過使用一個設備同時測試兩條線路，減少測試時間
• 實時運行雙向故障排除

Features

Mobile Network I&M

• Mobile Fronthaul and Backhaul - Optical Loss, Reflectance and ORL Measurements
  • Hybrid single mode fiber (1310 nm/1550 nm), multimode fiber (850 nm/1300 nm) models
  • 3 wavelength single mode fiber model (1310 nm/1550 nm/1625 nm, 1310 nm/1550 nm/1650 nm)
  • All-in-one OTDR, light source, optical power meter, visible light source (option)
  • Multi-pulse measurement for high-accuracy event detection
  • CPRI/OBSAI measurement with simultaneously installed Multi-rate Module MU100010A/MU100011A
  • Optical connector inspection with IEC 61300-3-35 Pass/Fail
• Easy-to-Use, Easy-to-Report
  • Graphical summary and Pass/Fail evaluation using Fiber Visualizer function
  • Intuitive touchscreen operation
  • One button, comprehensive PDF report generation

Core and Metro Network Long Range I&M

• Easily test long fibers 100 km or more
• Three single mode fiber (1310 nm/1550 nm) models: Standard, Enhanced, High-Performance
• 3 wavelength single mode fiber (1310nm/1550nm/1625nm) model: High-Performance
• Automated file naming/file saving and fast data acquisition reduce testing times
• Construction OTDR mode for cable installation: Automated testing of multiple fibers at multiple wavelengths

FTTx and PON I&M

• Easily test PON Networks with up to 1×128 count splitters
• Multi-pulse measurement for high splitter loss measurement and high resolution testing
• Splitter identification by size with individual Pass/Fail



Description

安裝復雜

隨著智能手機和平板電腦等移動設備在世界各地迅速普及，這些使用 SNS、視頻流的設備使數據流量呈現爆炸式增長。雖然移動網絡基站采用各種不同的方法配置，但天線無線電部分均通過通用接口 CPRI/OBSAI 以光纖實現 BBU 與 RRH 的連接。隨著移動環境的日益發展，對光纖故障探測與傳輸質量測試的需求也越來越多。而在測試專家 MT1000A 中安裝 10G 多速率模塊 MU100010A 和 OTDR 模塊 MU100020A/21A/22A/23A，能實現一體化光纖故障探測和傳輸質量測試。
利用 MU100020A/21A/22A/23A，通過過度的光反射，可探測出光纜連接處有刮損或污垢的連接器是故障位置，從而實現移動光纖的故障探測與故障排除。此外，通過光纖可視器功能實現使用方便、輕松報告的測試，還能極大地提高工作效率。

OTDR 模塊應用

一般來說，根據光纖測量的環境，OTDR 測量需要距離范圍、脈沖寬度、測量時間等多項設置。這讓一般情況下不使用 OTDR 的技術人員感到非常困難。對一個光電路執行通過/未通過評估來獲取報告時，一個簡單且直觀的 GUI 是提高工作效率的關鍵。
MU100020A/21A/22A/23A 的操作很簡單，它采用三種應用測量模式：Standard OTDR 測量、FTTA 測量、Construction測量和 OLTS 測量。

  Standard OTDR 測量

OTDR 測量結果顯示為一條軌跡，顯示光纖長度、損失和反射大小，并在光纖可視器屏幕上顯示分析結果報告。

• 事件圖標顯示每個連接器、接片和遠端的特性。
• 通過/未通過評估基于用戶可設置閾值

用戶可針對每個事件設置任意閾值。只要預先設定工程設計手冊中規定的通過/未通過評估設置，那么測量結束時，可輕松地看出所測量的光纖損耗狀態。

  FTTA 測量

移動前傳 FTTA 一般安裝長度約為幾百米的相對較短光纖。在此類測量環境中，不同運營商在不同條件下進行的測量通常會在之后的數據處理中出現不一致問題。
在 FTTA 測量中，由于事先確定了光纖安裝測量條件，所以不論是誰執行測量，始終都在相同的條件下進行。
與 OTDR 測量功能類似，每次測量結果都可以在跟蹤與光纖可視器屏幕上分析。

  Construction 測量

該“建構模式”簡化了安裝工作，在鋪設多核光纖電纜時尤其有用。通過利用項目數據（光纖的數量、文件名等）和測量條件等預設的自動化操作可以排除工作失誤，從而促使有效地測量多核光纖電纜。

  OLTS 測量

在測量光物理層時，一項基礎測量是使用光源和功率計進行的損耗測量。當內置光源和功率計為標配時，MU100020A/21A/22A/23A 便可被用作一個光損耗測試儀 (OLTS)此外，測量結果可以根據測試儀閾值，由各數據的通過/未通過評估的損耗表來管理。



規格

OTDR Module MU100020A

Options	MU100020A-020	MU100020A-021	MU100020A-022
Wavelength	1310 nm/1550 nm ±25 nm
Fiber Type	Single Mode Fiber (SMF) 10 µm/125 µm ITU-T G.652
Pulse Width	3, 10, 20, 50, 100, 200, 500, 1000, 2000, 4000, 10000, 20000 ns
Dynamic Range	39 dB/37.5 dB	42 dB/41 dB	46 dB/46 dB 25 dB/25 dB (Pulse Width: 100 ns)
Deadzone (Fresnel) (IOR = 1.500000)	≤80 cm (typ.)
Deadzone (Backscatter) (IOR = 1.500000)	≤3.8 m/4.3 m

OTDR Module MU100021A

Options	MU100021A-021
Wavelength	1310 nm/1550 nm ±25 nm	850 nm/1300 nm ±30 nm
Fiber Type	Single Mode Fiber (SMF) 10 µm/125 µm ITU-T G.652	GI Fiber 62.5 µm/125 µm
Pulse Width	3, 10, 20, 50, 100, 200, 500, 1000, 2000, 4000, 10000, 20000 ns	850 nm: 3, 10, 20, 50, 100, 200, 500 ns 1310 nm: 3, 10, 20, 50, 100, 200, 500, 1000, 2000, 4000 ns
Dynamic Range	42 dB/41 dB	29 dB/28 dB
Deadzone (Fresnel) (IOR = 1.500000)	≤80 cm (typ.)
Deadzone (Backscatter) (IOR = 1.500000)	≤3.8 m/4.3 m	≤4.0 m/5.0 m

OTDR Module MU100022A

Options	MU100022A-022
Wavelength	1310 nm/1550 nm/1625 nm ±25 nm
Fiber Type	Single Mode Fiber (SMF) 10 µm/125 µm ITU-T G.652
Pulse Width	3, 10, 20, 50, 100, 200, 500, 1000, 2000, 4000, 10000, 20000 ns
Dynamic Range	46 dB/46 dB/44 dB 25 dB/25 dB/23 dB (Pulse Width: 100 ns)
Deadzone (Fresnel) (IOR = 1.500000)	≤80 cm (typ.)
Deadzone (Backscatter) (IOR = 1.500000)	≤3.8 m/4.3 m/4.8 m

OTDR Module MU100023A

Options	MU100023A-021
Wavelength	1310 nm/1550 nm ±25 nm 1645 nm to 1655 nm
Fiber Type	Single Mode Fiber (SMF) 10 µm/125 µm ITU-T G.652
Pulse Width	3, 10, 20, 50, 100, 200, 500, 1000, 2000, 4000, 10000, 20000 ns
Dynamic Range	42 dB/41 dB/35 dB
Deadzone (Fresnel) (IOR = 1.500000)	≤80 cm (typ.)
Deadzone (Backscatter) (IOR = 1.500000)	≤5.0 m/5.5 m/6.5 m



• 以太網
• 光纖通道
• SyncE
• OTN、SDH/SONET、PDH/DSn
• OTDR
